Amal Aluminium Manufacturer and Supplier, based in Muscat, OMAN, specializes in providing high-quality aluminium products to meet diverse industrial needs. Committed to excellence, we offer a comprehensive range of aluminium solutions, including Aluminium 5754 Square Bars. These bars are renowned for their exceptional strength, corrosion resistance, and versatility, making them ideal for construction, automotive, and marine applications. Amal Aluminium combines advanced manufacturing techniques with superior customer service to deliver durable and reliable aluminium products that meet the highest quality standards.
5754 Aluminium square bars are composed primarily of aluminium (approximately 92.5-94%), with magnesium (2.60-3.60%) as the main alloying element. Small amounts of manganese (0.50%) and iron (0.7% max) are also present. This composition provides excellent corrosion resistance, good weldability, and high strength. The mechanical properties of Aluminium 5754 include a tensile strength of about 210 MPa, yield strength of around 130 MPa, and elongation of approximately 12%. These properties make it suitable for applications requiring high strength and good corrosion resistance, such as in marine environments and industrial applications.
Specification : ASTM B 221 ASME SB 221, B211, B565, B316 1100, AMS 4102
Standard : ASTM, BS and all International Standards
Temper : O, H12, H14, H16, H18, H22, H24, H26, H32, H112
Length : 100 mm To 3000 mm Long & Above
Size : 5 mm To 500 mm
| Aluminium 5754 | Fe | Si | Mg | Mn | Cu | Zn | Ti | Al |
| 0.40 | 0.40 | 2.60 – 3.60 | 0.50 | 0.10 | 0.20 | 0.15 | Bal |
| Thermal conductivity | Coefficient of thermal expansion | Melting point | Elastic modulus | Electrical conductivity | |||
|---|---|---|---|---|---|---|---|
| Alloy | Temper | W/m*K | µm/(m*K) | Min | Max | KN/mm2 | %IACS |
| EN AW-5754 | Hx2 | 132 | 23,7 | 595 | 645 | 70 | 32,5 |
| EN AW-5754 | Hx4 | 132 | 23,7 | 595 | 645 | 70 | 32,5 |
| EN AW-5754 | Hx6 | 132 | 23,7 | 595 | 645 | 70 | 32,5 |
| EN AW-5754 | Hx8 | 132 | 23,7 | 595 | 645 | 70 | 32,5 |
| EN AW-5754 | Hx9 | 23,7 | 595 | 645 | 70 | ||
| EN AW-5754 | O | 132 | 23,7 | 595 | 645 | 70 | 32,5 |
| STANDARD | UNS | WERKSTOFF NR. | European Standard | DIN | ISO | USA (AA) |
| Aluminium 5754 | A95754 | 3.3535 | EN AW-5754 | AlMg3 | AlMg3 | AA5754 |
Amal Aluminium based in Muscat, OMAN is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminum 5754 Square Bars to meet specific project needs. Our team at Amal Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@amalaluminium.com
Aluminium 5754 square bars are widely used in various industries due to their excellent corrosion resistance, high strength, and durability. They are ideal for marine applications, chemical processing equipment, and storage tanks where resistance to seawater and aggressive chemicals is crucial. These bars also find applications in the automotive industry for making vehicle components due to their lightweight and good machinability. Additionally, they are used in construction for structural components like beams and frames, offering a combination of strength, formability, and aesthetic appeal.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
