Amal Aluminium, located in Muscat, OMAN, is a trusted manufacturer and supplier of premium aluminium products, specializing in Aluminium 2014 Sheets and Plates. Renowned for their high strength, excellent machinability, and durability, our Aluminium 2014 sheets and plates are ideal for aerospace, automotive, and industrial applications. With superior resistance to corrosion and the ability to withstand high-stress environments, we provide tailored solutions to meet diverse industry needs. Choose Amal Aluminium for reliable and high-performance Aluminium 2014 sheets and plates.
Aluminium 2014 sheets and plates are alloyed primarily with copper, containing around 4-5% copper along with smaller amounts of manganese, silicon, and other elements. This composition provides high strength, excellent machinability, and good fatigue resistance. The material has a tensile strength of approximately 430-470 MPa and a yield strength of 350 MPa. It also exhibits moderate elongation (around 10-15%), making it suitable for applications that require high-strength materials but also some flexibility. Aluminium 2014 is commonly used in aerospace, military, and automotive industries due to its strength and performance under stress.
Standards : ASTM B209 / ASME SB209
Temper : O, T3,T4, T6, T651
Thickness : 0.2-250
Width : 100-2600
Length : 500-10000
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Sheet/ Plate Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Sheet
| Alloy | Si | Fe | Cu | Zn | Mn | Mg | Ti | Other | Cr | Ni | Others | Ti+Zr | Al |
| 2014 (min) (max) | 0.50 – 0.90 | 0.0 – 0.50 | 3.90 – 5.00 | 0.0 – 0.25 | 0.40 – 1.20 | 0.20 – 0.80 | 0.0 – 0.15 | 0.0 – 0.15 | 0.0 – 0.10 | 0.0 – 0.10 | 0.0 – 0.05 | 0.0 – 0.20 | Balance |
| Alloy | Temper | UTS (Mpa) | Yield Strength (Mpa) | Elongation (%) | ||
| – | – | Minimum | Maximum | Minimum | Maximum | A 50mm (Minimum) |
| EN AW-2014 | O | – | 250 | – | 135 | 10 |
| T4 | 370 | – | 230 | – | 11 | |
Amal Aluminium based in Muscat, OMAN is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
| European Standard | BS (OLD) | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) | IS | Canadian |
| EN AW-2014 | HE15 | 3.1255 | A92014 | AlCu4SiMg | 2014 | AlCuSiMn | 24345 | B26S |
| Sizes (mm) | Theoretical Mass KG/Plate |
|---|---|
| 2000 X 1000 X 0.5 | 2500 X 1250 X 0.5 |
| 2000 X 1000 X 0.7 | 2500 X 1250 X 0.7 |
| 2000 X 1000 X 0.9 | 2500 X 1250 X 0.9 |
| 2000 X 1000 X 1.2 | 2500 X 1250 X 1.2 |
| 3000 X 1500 X 1.2 | 2000 X 1000 X 1.6 |
| 2500 X 1250 X 1.6 | 3000 X 1500 X 1.6 |
| 2000 X 1000 X 2.0 | 2500 X 1250 X 2.0 |
| 3000 X 1500 X 2.0 | 2500 X 1250 X 2.5 |
| 2.79 | 4.36 |
| 3.91 | 6.10 |
| 5.02 | 7.85 |
| 6.74 | 10.46 |
| 15.01 | 8.93 |
| 13.95 | 20.09 |
| 11.16 | 17.44 |
| 25.11 | 21.80 |
Yes, we offer custom sizes for Aluminium 2014 Sheets and Plates to meet specific project needs. Our team at Amal Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@amalaluminium.com
Aluminium 2014 sheets and plates are widely used in industries that require high strength and excellent machinability. Due to their superior strength-to-weight ratio, they are ideal for aerospace and aviation applications, including aircraft structures, wings, and fuselage components. The alloy’s resistance to stress and fatigue also makes it suitable for military and defense applications, such as missile parts and structural components. Additionally, Aluminium 2014 is used in automotive industries for manufacturing high-performance parts, and in marine environments for applications that demand strength and resistance to corrosion.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
